Main Cylinder
125x900st
Horse Power
10Hp
20Hp
7.5K.W
15 K.W
Bale Dimensions WxHxL (mm)
500 x 500 x variable length (mm)
Bale weight
70kgs+++
Feed Opening Dimensions(mm)
625 x 460
Bale Chamber(mm)
500 x 500 x 900
Bale Density(O.C.C)
450 - 500(kg/m3)
Max Thrust Force
21 Ton (170kg/cm3)
Cycle Time (Unload)
13.8 sec
20 HP
Production (40-60kg/m3)
1-1.5 TPH
1.7-2.2 TPH
Number of ties
3
Wire Size (mm)
2.4 -2.7 (mm)
Oil Reservoir
280 L
500 L
Machine Weight
3000 kgs
3500 kgs
