Main Cylinder(mm)
D250
Horse Power
60Hp
45kW
Feed Opening Dimensions(mm)
1600 × 710
Bale Chamber(mm)
750 × 1100 × 3200
Bale Dimensions WxHxL (mm)
750 × 1100 × 1400 (Max.)
Production (OCC BASIC)(TPH)
2~3
Max Thrust Force
118000kg(240kg/cm2)
Cycle Time (Unload) ( kg/ m2)
14.3 sec
Cycle Time
(UNLOAD)(60 Hz & 1800rpm)
19.5 sec
Bale Density ( kg/ m3)
500~600
Alumn. Can ( kg/ m3))
350~450
Tin. Can ( kg/ m3)
550~720
PET( kg/ m3)
350~450
HDPE ( kg/ m3)
450~600
Plastic Film ( kg/ m3)
450~550
Wire Size (mm)
5
Machine Weight
15000kgs
