Main Cylinder(mm)
D250
Horse Power
40 HP
40kW
Feed Opening Dimensions(mm)
800 × 710
Bale Chamber(mm)
750 × 750 × 2200
Bale Dimensions WxHxL (mm)
750 × 750 × 1400 (Max.)
Production (OCC BASIC)(TPH)
4~5 (TIN CANS)
Max Thrust Force
118000kg(240kg/cm2)
Cycle Time (Unload) ( kg/ m2)
20.8
Cycle Time
(UNLOAD)(60 Hz & 1800rpm)
22 sec
Bale Density ( kg/ m3)
-
Alumn. Can ( kg/ m3))
420~500
Tin. Can ( kg/ m3)
680~720
PET( kg/ m3)
-
HDPE ( kg/ m3)
-
Plastic Film ( kg/ m3)
-
Wire Size (mm)
4
Machine Weight
11000kgs
