Main Cylinder
φ224 × 2400st
φ224 × 2900st
Horse Power
40 HP
60 HP
60 HP
80 HP
30kW
45kW
45kW
30kW x2
Bale Dimensions WxHxL (mm)
1100 x 750 x variable length (mm)
Bale Weight
680KGS+++
Feed Opening Dimensions LxW (mm)
1800 × 1020
2400 × 1020
Bale Chamber(mm)
1100 × 750 × 2400
1100 × 750 × 2900
Bale density (O.C.C)
500~600 (kg/ m3)
Max.Thrust Force
95 Ton (240kg / cm2)
75 Ton (240kg / cm2)
95 Ton (240kg / cm2)
Cycle Time (Unload)
18.8 sec
12.7 sec
15.3 sec
12.3 sec
Production (40~60 kg/ m3)
8.5~11 TPH
10~14 TPH
11.5~15 TPH
13~17 TPH
Number of Ties
4
Wire Size (mm)
2.7(㎜)
Oil Reservoir
1360 L
1500 L
2000L
Machine Weight
12500kgs
13000 kgs
14000kgs
