Main Cylinder
250x24000st
Horse Power
80Hp
120Hp
30kW x2
45kW x2
Bale Dimensions WxHxL (mm)
1100 x 1100 x varible length (mm)
Bale weight
1000kgs+++
Feed Opening Dimensions(mm)
1800 x 1020
Bale Chamber(mm)
1100 x 1100 x 2400
Bale Density(O.C.C)
500-600(kg/m3)
Max Thrust Force
118000kg(240kg/cm2)
Cycle Time (Unload)
11.8 sec
7.9 sec
Production (40-60kg/m3)
15~21 TPH
22~28.5 TPH
Number of ties
5
Wire Size (mm)
2.7 (mm)
Oil Reservoir
2000L
Machine Weight
225000kgs
235000kgs
