Main Cylinder
Ø150 × 1600st
Ø180 × 1600st
Horse Power
20 HP
30 HP
40 HP
20 HP
30 HP
40 HP
15 K.W
22.5 K.W
30 K.W
15 K.W
22.5 K.W
30 K.W
Bale Dimensions WxHxL (mm)
750 x 750 x variable length (mm)
Bale weight
350kgs+++
Bale Chamber WxHxL (mm)
750 × 750 × 1600
Bale Density (O.C.C)
450~550 (kg/ m3)
500~600 (kg/ m3)
Max.Thrust Force
37 Ton (210kg / cm2)
53 Ton (210kg / cm2)
Cycle Time (Unload)
17.9 sec
12 sec
6 sec
25.2 sec
16.8 sec
8.7 sec
Production (40~60 kg/ m3)
4~5 TPH
5~6.5 TPH
7~9.5 TPH
3~4 TPH
4.5~5 TPH
6~8 TPH
Number of Ties
4
Wire Size (mm)
2.7(㎜)
Oil Reservoir
560 L
Machine Weight
7000 kgs/ 8000 kgs
