Main Cylinder
D125
Ejector Cylinder (mm)
D100
Horse Power
10Hp
20Hp
7.5K.W
15 K.W
Feed Opening Dimensions(mm)
625 x 460
Bale Chamber WxHxL (mm)
500 × 500 × 1675
Bale Dimensions WxHxL (mm)
500 × 500 × 750
Production (OCC BASIC)(TPH)
1~1.5 (FINE PAPER)
1.5~2.5 (FINE PAPER)
Max Thrust Force
21 Ton (175kg / cm2)
Cycle Time (Unload) ( kg/ m2)
8.4
20 HP
Cycle Time
(UNLOAD)(60 Hz & 1800rpm)
23.1 sec
11.5 sec
Wire Size (mm)
15 mm (P.P帶 P.P BAND)
Machine Weight
3000kgs
3500kgs
